论文解读：
常见的并行训练的模式有两种：

同步，各个worker并行训练，每次更新梯度时都等待所有worker完成本次迭代的计算，然后一起开始下一次迭代。最简单的同步就是每个worker的梯度求和求平均，然后更新参数，目前比较流行的同步更新方法则是ring-all-ruduce方法。可以保证梯度的正确性。但是速度较慢。
完全异步，各个worker并行训练，各自处理各自的数据不等待其他任何worker。速度比较快，但是梯度有损失。
存在的问题：传统的SGD是基于batch更新的，并行训练时各个worker计算当前batch的梯度，然后反向传播之后push梯度，然后pull最新的参数再处理下一个batch。这个时候如果当一个worker更新速度特别慢，这个worker push的梯度是使用一个非常旧的参数计算出来的，这个梯度可能已经不适合当下的参数，甚至有时候会起到反作用。

本文提出的SSP方法来让worker在效率和正确性上做一个良好的权衡。

核心思想：各个worker并行训练，每次进行下一次迭代时判断一下自己的迭代比整个系统中最慢的节点的迭代快多少个step，如果达到一个阈值就进入等待状态直到step小于阈值开始下一次计算。

代码实现

参考：https://blog.csdn.net/li57681522/article/details/87920210

# -*- coding:utf-8 -*-

# python dis_tf_ssp.py --job_name=ps --task_index=0
# python dis_tf_ssp.py --job_name=worker --task_index=0
# python dis_tf_ssp.py --job_name=worker --task_index=1

import time
import numpy as np
import tensorflow as tf

from tensorflow.python.util.tf_export import tf_export
from tensorflow.python.ops import state_ops, variables, variable_scope
from tensorflow.python.training import session_run_hook

# Define parameters
FLAGS = tf.app.flags.FLAGS
tf.app.flags.DEFINE_float('learning_rate', 0.00003, 'Initial learning rate.')
tf.app.flags.DEFINE_integer('steps_to_validate', 1000,
                            'Steps to validate and print loss')

# For distributed
tf.app.flags.DEFINE_string("ps_hosts", "172.20.181.16:2222",
                           "Comma-separated list of hostname:port pairs")
tf.app.flags.DEFINE_string("worker_hosts", "172.20.181.16:2224",
                           "Comma-separated list of hostname:port pairs")
tf.app.flags.DEFINE_string("job_name", "worker", "One of 'ps', 'worker'")
tf.app.flags.DEFINE_integer("task_index", 0, "Index of task within the job")

# Hyperparameters
learning_rate = FLAGS.learning_rate
steps_to_validate = FLAGS.steps_to_validate


# @tf_export("train.SemiSyncRunHook")
# class SemiSyncRunHook(session_run_hook.SessionRunHook):
class SemiSyncRunHook(tf.train.SessionRunHook):
    """Run by SSP."""

    def __init__(self, index, worker_count, staleness=10):
        """Initializes a `SemiSyncRunHook`.
        Args:
          index: work index
          worker_count: number of workers
          staleness:
        """

        if index >= worker_count:
            print("worker index {} is bigger than worker_count {}".format(index, worker_count))
            return

        self._const_max_test_step = 10000
        self._last_step = 0  # 上一次wait的步骤数
        self._last_time = self._now_time()  # 上一次wait的时间

        self._index = index
        self._staleness = staleness
        self._wait_time = 0.01  # 等待时间，单位：秒；这个时间不能设置的太长，跟worker的训练速度和staleness相关
        self._worker_steps = []  # 记录worker训练步骤数的变量列表

        for i in range(worker_count):
            worker_step = variable_scope.variable(0, trainable=False, name="worker_step_" + str(i))
            self._worker_steps.append(worker_step)
            if i == index:
                self._my_step_update_op = state_ops.assign_add(worker_step, 1)

        self._initialize_op = variables.variables_initializer(self._worker_steps)

    def _now_time(self):
        return time.time()

    def after_create_session(self, session, coord):
        session.run(self._initialize_op)  # 初始化记录worker训练步骤数的变量

    def before_run(self, run_context):
        run_context.session.run(self._my_step_update_op)  # 更新本worker的训练步骤数
        return None

    def after_run(self, run_context, run_values):
        while True:
            # 1.获取所有worker的训练步骤数
            all_worker_steps = run_context.session.run(self._worker_steps)
            # print("all worker steps={}. my work id={}".format(all_worker_steps, self._index))

            # 2.如果训练当前worker的训练步骤数 > 最小worker训练步骤数 + staleness，sleep(10ms); 否则 break;
            if all_worker_steps[self._index] > min(all_worker_steps) + self._staleness:
                diff_step = all_worker_steps[self._index] - self._last_step
                if diff_step / self._const_max_test_step > 1:
                    self._wait_time = (self._now_time() - self._last_time) / diff_step * self._staleness * 0.7

                    # 更新
                    self._last_step = all_worker_steps[self._index]
                    self._last_time = self._now_time()

                time.sleep(self._wait_time)  # 等待慢worker执行
                # print("all worker steps={}, my work id={}. waiting {}s...".format(all_worker_steps, self._index, self._wait_time))
            else:
                break


def main(_):
    ps_hosts = FLAGS.ps_hosts.split(",")
    worker_hosts = FLAGS.worker_hosts.split(",")
    cluster = tf.train.ClusterSpec({"ps": ps_hosts, "worker": worker_hosts})
    server = tf.train.Server(cluster, job_name=FLAGS.job_name, task_index=FLAGS.task_index)

    worker_count = len(worker_hosts)

    if FLAGS.job_name == "ps":
        server.join()
    elif FLAGS.job_name == "worker":
        with tf.device(tf.train.replica_device_setter(
                worker_device="/job:worker/task:%d" % FLAGS.task_index,
                cluster=cluster)):
            global_step = tf.Variable(0, name='global_step', trainable=False)

            X = tf.placeholder(tf.float32)
            Y = tf.placeholder(tf.float32)
            w = tf.Variable(0.0, name="weight")
            b = tf.Variable(0.0, name="reminder")
            y = w * X + b

            loss = tf.reduce_mean(tf.square(y - Y))
            optimizer = tf.train.GradientDescentOptimizer(learning_rate)

            # 更新梯度
            train_op = optimizer.minimize(loss, global_step=global_step)

            hooks = [tf.train.StopAtStepHook(last_step=1000000)]

            semiSyncRunHook = SemiSyncRunHook(FLAGS.task_index, worker_count=worker_count, staleness=10)
            hooks.append(semiSyncRunHook)

            with tf.train.MonitoredTrainingSession(
                    master=server.target, is_chief=(FLAGS.task_index == 0),
                    checkpoint_dir="./ssp_saved_model",
                    hooks=hooks) as mon_sess:
                while not mon_sess.should_stop():
                    train_x = np.random.randn(1)
                    train_y = 2 * train_x + np.random.randn(1) * 0.33 + 10
                    _, loss_v, step = mon_sess.run([train_op, loss, global_step], feed_dict={X: train_x, Y: train_y})
                    if step % steps_to_validate == 0:
                        w_, b_ = mon_sess.run([w, b])
                        print("step: %d, weight: %f, biase: %f, loss: %f" % (step, w_, b_, loss_v))


if __name__ == "__main__":
    tf.app.run()

参考文献：

More Effective Distributed ML via a Stale Synchronous Parallel Parameter Server

本文转载自Alex-zhai知乎账号。

原文链接：https://zhuanlan.zhihu.com/p/69665236

创作场景

Stale Synchronous Parallel Parameter Server 解读和代码实现
