GBase 8a MPP 集群扩容实战

-- root用户scp -r ~/.ssh 192.168.200.12:~/-- gbase用户scp -r ~/.ssh 192.168.200.12:~/

-- root用户vi /etc/c3.conf 添加cluster new {     192.168.200.11:redhat1     192.168.200.12}

-- 操作系统cexec new_data: new: 'cat /etc/redhat-release'-- 内核cexec new_data: new: 'uname -a'-- 防火墙cexec new_data: new: 'service iptables status'cexec new_data: new: 'service ip6tables status'cexec new_data: new: 'chkconfig | grep iptables'cexec new_data: new: 'chkconfig | grep ip6tables'-- selinuxcexec new_data: new: 'sestatus'cexec new_data: new: 'grep ^SELINUX= /etc/selinux/config'-- 内存参数cexec new_data: new: 'ulimit -H'cexec new_data: new: 'ulimit -S'cexec new_data: new: 'ulimit -m'-- vi /etc/security/limits.config 添加-- * soft as unlimited-- * hard as unlimited-- * rss as unlimited-- 透明大页cexec new_data: new: 'cat /sys/kernel/mm/redhat_transparent_hugepage/enabled'-- echo "never" > /sys/kernel/mm/redhat_transparent_hugepage/enabled-- 主机名检查cexec new_data: new: 'hostname'

-- 修改/etc/hostsvi /etc/hosts 添加新增节点信息并同步到新增节点-- 确认集群正常gcadmingcadmin showddleventgcadmin showdmleventgcadmin showdmlstorageevent-- 设置集群readonlygcadmin switchmode readonly-- scn tableid 备份cexec 'python -c "import gcware;print gcware.getscn()"'cexec 'python -c "import gcware;print gcware. gettableid ()"'-- 版本信息查看cexec "/opt/gcluster/server/bin/gclusterd -V"cexec "gcadmin -V"cexec data: "/opt/gnode/server/bin/gbased -V"cexec 'gccli -ugbase -pgbase20110531 -Nse "select @@version"'-- 数据库信息备份sh backup_database.shls -l /home/gbase/gbase_expand/201811-- nodedatamap备份gccli -ugbase -pgbase20110531 -vvv -e"rmt:select * from gbase.nodedatamap  into outfile '/home/gbase/gbase_expand/201811/nodedatamap.dat' fields terminated by '|'"wc -l /home/gbase/gbase_expand/201811/nodedatamap.dat-- 备份集群配置文件cexec "mkdir -p /home/gbase/gbase_expand/201811/gcluster"cexec "cp -r /opt/gcluster/config/ /home/gbase/gbase_expand/201811/gcluster/"cexec "ls /home/gbase/gbase_expand/201811/gcluster/config"cexec data: "mkdir -p /home/gbase/gbase_expand/201811/gnode"cexec data: "cp -r /opt/gnode/config/ /home/gbase/gbase_expand/201811/gnode/"cexec coor: "ls /home/gbase/gbase_expand/201811/gnode/config"-- 备份corosync配置文件cexec "cp -r /etc/corosync /home/gbase/gbase_expand/201811/"cexec "ls /home/gbase/gbase_expand/201811/corosync | wc -l"-- 备份gcware配置文件cexec "cp -r /var/lib/gcware /home/gbase/gbase_expand/201811/"cexec 'ls /home/gbase/gbase_expand/201811/gcware | wc -l'

-- 停止集群cexec "service gcware stop"
--找到原来的升级包所在的目录-- 修改demo.optionscd gcinstall/vi demo.optionsinstallPrefix= /optcoordinateHost = dataHost = 134.32.48.8,134.32.48.11,134.32.48.13,134.32.48.14,134.32.48.46,134.32.48.47,134.32.48.48,134.32.48.50existCoordinateHost =134.32.48.208,134.32.48.209,134.32.48.210,134.32.48.211,134.32.48.212,134.32.48.213,134.32.48.214,134.32.48.215,134.32.48.216,134.32.48.217,134.32.48.218,134.32.48.219,134.32.48.220,134.32.48.221,134.32.48.222,134.32.48.223,134.32.48.224,134.32.48.225,134.32.48.226,134.32.48.227existDataHost =134.32.48.208,134.32.48.209,134.32.48.210,134.32.48.211,134.32.48.212,134.32.48.213,134.32.48.214,134.32.48.215,134.32.48.216,134.32.48.217,134.32.48.218,134.32.48.219,134.32.48.220,134.32.48.221,134.32.48.222,134.32.48.223,134.32.48.224,134.32.48.225,134.32.48.226,134.32.48.227loginUser= rootloginUserPwd = ' Huawei#123'#loginUserPwdFile = loginUserPwd.jsondbaUser = gbasedbaGroup = gbasedbaPwd = gbaserootPwd = ' Huawei#123'#rootPwdFile = rootPwd.jsondbRootPwd = 'Huawei@123'#mcastAddr = 226.94.1.39mcastPort = 5493

-- 执行扩容./gcinstall.py --silent=demo.options-- 配置文件对比diff /opt/gcluster/config/gbase_8a_gcluster.cnf /home/gbase/gbase_expand/201811/gcluster/config/gbase_8a_gcluster.cnf diff /opt/gnode/config/gbase_8a_gbase.cnf /home/gbase/gbase_expand/201811/gnode/config/gbase_8a_gbase.cnfcexec data: md5sum /opt/gnode/config/gbase_8a_gbase.cnf-- 生成新的distribution（备份方式）gcadmin distribution gcChangeInfo.xml p 1 d 1-- 生成新的hashmapgccli -ugbase -pgbase20110531 -vvv -e"initnodedatamap"

增删改查测试create database db_test;create table db_test.t1(c1 int,c2 int) distributed by ('c1');insert into db_test.t1 values (1,1),(2,2),(3,3);update db_test.t1 set c2=10 where c1=1;select * from db_test.t1;delete from db_test.t1 where c1>=3;select * from db_test.t1;truncate table db_test.t1;数据加载测试load data infile 'sftp://gbase:gbase@192.168.200.11/tmp/t1.txt' into table db_test.t1 fields terminated by ':';select count(1) from db_test.t1;drop table db_test.t1;drop database db_test;

-- 重分布-- 设置重分布并发度为0gccli -ugbase -pgbase20110531 -vvv -e"set global gcluster_rebalancing_concurrent_count=0"gccli -ugbase -pgbase20110531 -Ns -e"select @@gcluster_rebalancing_concurrent_count"-- 重分布整个实例gccli -ugbase -pgbase20110531 -vvv -e"rebalance instance"gccli -ugbase -pgbase20110531 -Ns -e"select count(1) from gclusterdb.rebalancing_status"-- 调整优先级create table test.reb_tab(db_name varchar(64),table_name varchar(64),priority int) replicated;-- 插入优先级高的表insert into test.reb_tab values ('test','t1',1),('test','t2',2);update gclusterdb.rebalancing_status a, test.reb_tab b set a.priority=b.priority where a.db_name=b.db_name and a.table_name=b.table_name ;select count(1) from gclusterdb.rebalancing_status where priority<5; -- 调整重分布并发度gccli -ugbase -pgbase20110531 -vvv -e"set global gcluster_rebalancing_concurrent_count=1"gccli -ugbase -pgbase20110531 -Ns -e"select @@gcluster_rebalancing_concurrent_count"-- 暂停重分布gccli -ugbase -pgbase20110531 -vvv -e"pause rebalance instance"gccli -ugbase -pgbase20110531 -Ns -e"select status,count(1) from gclusterdb.rebalancing_status group by 1"-- 继续重分布gccli -ugbase -pgbase20110531 -vvv -e"continue rebalance instance"gccli -ugbase -pgbase20110531 -Ns -e"select status,count(1) from gclusterdb.rebalancing_status group by 1"-- 等待重分布完成-- 恢复业务
