在 EKS 平台上合并 ALB Ingress Controller

Kubernetes Ingress 是一种 API 对象，借助它可以管理对集群中运行的 Kubernetes 服务的外部（或）内部 HTTPS访问，通过ALB ingress controller可以在kubernetes上部署服务时自动触发创建 ALB 以及必要的 AWS 支持资源。下图详细描述了用户定义了 Ingress 资源时 aws-alb-ingress-controller 将会创建的 AWS 组件。
[](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform1.png)](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform1.jpg)


当客户在EKS上部署微服务时，他们发现AWS ALB Ingress Controller会为每个入口资源创建一个新的ALB。 当客户有数百个微服务时，也会生成数百个ALB，从管理和经济成本上分析，可能会让客户的使用成本变得非常高。 所以支持跨ingress资源重用ALB是客户的一个重要需求。 此外，每个帐户ALB的数量限制为50个,如果超过此限制需要不断的提升ALB的数量，这增加了客户运维的风险和负担。因此，针对这个现状，结合开源项目实现了一套合并ALB ingress controller的方法来解决客户的问题，其原理是：合并Ingress Controller并允许创建ingress资源，这些ingress资源将被组合在一起以创建将由同一控制器管理的新入口资源，工作流程见下图：
[](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform2.png)](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform2.jpg)




## 2.  合并过程
### 1)  前置条件
* Create an AWS account* Create a Workspace* Create an SSH key* Install Kubernetes Tools* Create an IAM role for your Workspace* Attach the IAM role to your Workspace* Update IAM settings for your Workspace
Note: 前置条件过程可以参考链接: https://eksworkshop.com/eksctl/


### 2)  安装kubectl过程
**创建安装目录（可选）**
YAML

   $mkdir -p ~/.kube

#### 安装kubectl:
YAML

   $sudo curl --silent --location -o /usr/local/bin/kubectl " https://storage.googleapis.com/kubernetes-release/release/v1.14.9/bin/linux/amd64/kubectl" sudo chmod +x /usr/local/bin/kubectl

#### 安装AWS IAM Authenticator（或升级到AWS CLI 的版本 1.16.232 或更高版本中）:
YAML

   $ go get -u -v github.com/kubernetes-sigs/aws-iam-authenticator/cmd/aws-iam-authenticator
   sudo mv ~/go/bin/aws-iam-authenticator /usr/local/bin/aws-iam-authenticator

#### 注：AWS CLI 的版本 1.16.232 或更高版本中可用的 aws eks get-token 命令支持客户端安全令牌创建
#### ，所以也可以升级当前的AWS cli到最新版本，可以参考如下链接：
https://docs.aws.amazon.com/zh_cn/cli/latest/userguide/install-cliv2-linux.html


#### 安装JQ:
sudo yum -y install jq


**下载与安装** ****[](https://eksctl.io/) **:**
YAML

   $curl --silent --location "https://github.com/weaveworks/eksctl/releases/download/latest_release/eksctl_$(uname -s)_amd64.tar.gz" | tar xz -C /tmp
   $sudo mv -v /tmp/eksctl /usr/local/bin
   $eksctl version

###
### 3)  创建EKS 集群（命令行中的AWS_REGION换成真实region）并开启访问alb-ingress权限
YAML

   $eksctl create cluster --name=eksworkshop-eksctl --nodes=3 --node-ami=auto --region=${AWS_REGION} --alb-ingress-access
   $kubectl get nodes

###
### 4)  部署Ingress_controller
YAML

   $kubectl apply -f https://raw.githubusercontent.com/kubernetes-sigs/aws-alb-ingress-controller/v1.1.3/docs/examples/rbac-role.yaml
   $ curl -sS "https://raw.githubusercontent.com/kubernetes-sigs/aws-alb-ingress-controller/v1.0.0/docs/examples/alb-ingress-controller.yaml" > alb-ingress-controller.yaml


   Note:Change the parameter of alb-ingress-controller.yaml:–cluster-name = cluster-name
   $ kubectl apply -f alb-ingress-controller.yaml
   $kubectl logs -n kube-system $(kubectl get po -n kube-system | egrep -o alb-ingress[a-zA-Z0-9-]+)

### 5)  安装Ingress-Merge
YAML

   $helm install --namespace kube-system --name ingress-merge ./helm

###
### 6)  部署demo application 2048
YAML

   $curl -sS "https://raw.githubusercontent.com/kubernetes-sigs/aws-alb-ingress-controller/v1.1.3/docs/examples/2048/2048-namespace.yaml" > 2048-namespace.yaml
   $ curl -sS "https://raw.githubusercontent.com/kubernetes-sigs/aws-alb-ingress-controller/v1.1.3/docs/examples/2048/2048-deployment.yaml " > 2048-deployment.yaml
   $ curl -sS "https://raw.githubusercontent.com/kubernetes-sigs/aws-alb-ingress-controller/v1.1.3/docs/examples/2048/2048-service.yaml" > 2048-service.yaml
   $kubectl apply -f 2048-namespace.yaml
   $kubectl apply -f 2048-deployment.yaml
   $kubectl apply -f 2048-service.yaml

### 7)  部署demo application echoserver
YAML

   $ curl -sS "https://github.com/kubernetes-sigs/aws-alb-ingress-controller/blob/master/docs/examples/echoservice/echoserver-deployment.yaml" > echoserver-deployment.yaml
   $ curl -sS "https://github.com/kubernetes-sigs/aws-alb-ingress-controller/blob/master/docs/examples/echoservice/echoserver-service.yaml" > echoserver-service.yaml

#### **Note**: 修改echoserver相关的yaml文件中的namespace为同一个.
###
### 8)  创建configmap
YAML

   $ cat merge-ingress-cm.yaml
   apiVersion: v1
   kind: ConfigMap
   metadata:
     name: merged-ingress
     namespace: game
   data:
     annotations: |
       kubernetes.io/ingress.class: alb
       alb.ingress.kubernetes.io/scheme: internet-facing
   $kubectl apply -f merge-ingress-cm.yaml

### 9)  创建Merge ingress
YAML

   $ cat merge-ingress.yaml
   apiVersion: extensions/v1beta1
   kind: Ingress
   metadata:
     name: echoserver-ingress
     namespace: game
     annotations:
       kubernetes.io/ingress.class: merge
       merge.ingress.kubernetes.io/config: merged-ingress
     labels:
       app: echoserver-ingress
   spec:
     rules:
       - http:
           paths:
             - path: /echo
               backend:
                 serviceName: echoserver
                 servicePort: 8080
   ---
   apiVersion: extensions/v1beta1
   kind: Ingress
   metadata:
     name: "2048-ingress"
     namespace: "game"
     annotations:
       kubernetes.io/ingress.class: merge
       merge.ingress.kubernetes.io/config: merged-ingress
     labels:
       app: 2048-ingress
   spec:
     rules:
       - http:
           paths:
             - path: /*
               backend:
                 serviceName: "service-2048"
                 servicePort: 80
   $kubectl apply -f merge-ingress.yaml


   $ cat ingress.yaml
   apiVersion: extensions/v1beta1
   kind: Ingress
   metadata:
     name: merged-ingress
     namespace: game
     annotations:
       kubernetes.io/ingress.class: alb
       alb.ingress.kubernetes.io/scheme: internet-facing
   spec:
     rules:
       - http:
           paths:
           - path: /echo
             backend:
               serviceName: echoserver
               servicePort: 8080
           - path: /game
             backend:
               serviceName: service-2048
               servicePort: 80

$kubectl apply -f ingress.yaml


### 10) 检查生成的ALB和对应的规则
[](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform3.png)](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform3.jpg)  [](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform4.png)](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform4.jpg)
###
### 11) 访问这个服务来验证，出现如下内容即表示成功
第一个是echoserver:
[](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform5.png)](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform5.jpg)


第二个是2048：
[](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform6.png)](https://s3.cn-north-1.amazonaws.com.cn/awschinablog/merging-alb-progress-controller-on-the-eks-platform6.jpg)


#### 注：请自行修改nginx中对于path的处理逻辑。
###
### 12) 总结
通过ingress-merge-controller将服务对应的rules附加到ALB上，这样我们完成了原来需要两个ALB合并成一个ALB的目的，减少了客户管理的ALB的数量并由此可以降低成本。
需要提醒大家以下几点：
* Ingress controller 只支持http 和Https协议；* 服务只支持nodeport和Loadbalancer 类型，即：Type=NodePort 或Service.Type=LoadBalancer
###
### 13) 参考资料
https://github.com/jakubkulhan/ingress-merge
https://github.com/kubernetes-sigs/aws-alb-ingress-controller
