实现输出函数

通过逻辑回归 w, b 以及输入 X，计算 Y 的预测值 A

向量化逻辑回归的输出函数

def predict(w, b, X):
    '''
    Arguments:
    w -- 权重, 一个行向量 (num_px * num_px * 3, 1)
    b -- 偏差, 一个标量
    X -- 标准化后的 X 矩阵，shape 为 (num_px * num_px * 3, number of examples)

    Returns:
    Y_prediction -- 一个包含了0，1，即对应 X 的预测值的向量
    '''

    m = X.shape[1]
    Y_prediction = np.zeros((1, m))
    w = w.reshape(X.shape[0], 1)

    # 计算结果 A 为一个列向量
    A = sigmoid(np.dot(w.T, X) + b)

    for i in range(A.shape[1]):
        # 将列向量 A 中的可能性比率大于 0.5 作为 1， 否则为 0
        Y_prediction[0, i] = 1 if A[0, i] > 0.5 else 0

    assert(Y_prediction.shape == (1, m))

    return Y_prediction

构建逻辑回归模型

调用上面已经实现的函数，构建逻辑回归模型。

def model(X_train, Y_train, X_test, Y_test, num_iterations=2000, learning_rate=0.5, print_cost=False):
    '''
    Arguments:
    X_train -- 训练集 X 维度，shape 为 (num_px * num_px * 3, m_train)
    Y_train -- 训练集 Y 维度，shape 为 (1, m_train)
    X_test -- 测试集 X 维度，shape 为 (num_px * num_px * 3, m_test)
    Y_test -- 测试集 Y 维度，shape 为 (1, m_test)
    num_iterations -- 迭代次数/优化更新次数（超参数）
    learning_rate -- 梯度下降的学习率/更新步长（超参数）
    print_cost -- 是否打印损失，默认不打印

    Returns:
    d -- 包含了模型详情信息的字典
    '''

    # 使用 X_train 的第一维度为参数，初始化 w, b 参数
    w, b = initialize_with_zeros(X_train.shape[0])

    # 梯度下降算法优化 w, b 参数
    parameters, grads, costs = optimize(w, b, X_train, Y_train, num_iterations, learning_rate, print_cost)

    # 取出 w, b 参数
    w = parameters["w"]
    b = parameters["b"]

    # 计算训练集和测试集的预测值
    Y_prediction_train = predict(w, b, X_train)
    Y_prediction_test = predict(w, b, X_test)

    # 打印训练集和测试集的准确率
    print("train accuracy: {} %".format(100 - np.mean(np.abs(Y_prediction_train - Y_train)) * 100))
    print("test accuracy: {} %".format(100 - np.mean(np.abs(Y_prediction_test - Y_test)) * 100))


    d = {"costs": costs,
         "Y_prediction_test": Y_prediction_test,
         "Y_prediction_train" : Y_prediction_train,
         "w" : w,
         "b" : b,
         "learning_rate" : learning_rate,
         "num_iterations": num_iterations}

    return d

训练模型

传入参数，调用模型函数，进行训练和验证。

d = model(train_set_x, train_set_y, test_set_x, test_set_y, num_iterations = 2000, learning_rate = 0.005, print_cost = True)

Cost after iteration 0: 0.693147
Cost after iteration 100: 0.584508
Cost after iteration 200: 0.466949
Cost after iteration 300: 0.376007
Cost after iteration 400: 0.331463
Cost after iteration 500: 0.303273
Cost after iteration 600: 0.279880
Cost after iteration 700: 0.260042
Cost after iteration 800: 0.242941
Cost after iteration 900: 0.228004
Cost after iteration 1000: 0.214820
Cost after iteration 1100: 0.203078
Cost after iteration 1200: 0.192544
Cost after iteration 1300: 0.183033
Cost after iteration 1400: 0.174399
Cost after iteration 1500: 0.166521
Cost after iteration 1600: 0.159305
Cost after iteration 1700: 0.152667
Cost after iteration 1800: 0.146542
Cost after iteration 1900: 0.140872
train accuracy: 99.04306220095694 %
test accuracy: 70.0 %

研究学习率、损失和更新次数的关系

绘制逻辑回归模型的学习曲线

costs = np.squeeze(d['costs'])
plt.plot(costs)
plt.ylabel('cost')
plt.xlabel('iterations (per hundreds)')
plt.title("Learning rate =" + str(d["learning_rate"]))
plt.show()

比较不同学习率下的学习曲线

learning_rates = [0.01, 0.001, 0.0001]
models = {}
for i in learning_rates:
    print ("learning rate is: " + str(i))
    models[str(i)] = model(train_set_x, train_set_y, test_set_x, test_set_y, num_iterations = 1500, learning_rate = i, print_cost = False)
    print ('\n' + "-------------------------------------------------------" + '\n')

for i in learning_rates:
    plt.plot(np.squeeze(models[str(i)]["costs"]), label= str(models[str(i)]["learning_rate"]))

plt.ylabel('cost')
plt.xlabel('iterations')

legend = plt.legend(loc='upper center', shadow=True)
frame = legend.get_frame()
frame.set_facecolor('0.90')
plt.show()

使用分类器

使用已经训练好的猫咪分类模型对任一图片进行分类判断。

my_image = "cat_in_iran.jpg"

# 对图片预处理，使之适用于模型
fname = "../input/images/" + my_image

image = np.array(plt.imread(fname))

# 查看图片
plt.imshow(image)

# 使用模型进行预测，并输出结果
my_image = np.array(Image.fromarray(image).resize((num_px, num_px),Image.ANTIALIAS)).reshape((1, num_px * num_px * 3)).T

my_predicted_image = predict(d["w"], d["b"], my_image)

print("y = " + str(np.squeeze(my_predicted_image)) + ", your algorithm predicts a \"" + classes[int(np.squeeze(my_predicted_image)),].decode("utf-8") +  "\" picture.")

y = 1.0, your algorithm predicts a "cat" picture.

第三章使用 TensorFlow 实现浅层神经网络进行猫咪识别

导入所需的package

import tensorflow as tf
import numpy as np
import matplotlib.pyplot as plt
from loadH5File import load_data
from PIL import Image

%matplotlib inline

加载数据集 (cat / non-cat)

train_set_x, train_set_y, test_set_x, test_set_y, classes = load_data()

train_x (209, 64, 64, 3) test_x (50, 64, 64, 3)
train_y (209, 1) test_y (50, 1)

其中loadH5File模块中定义了处理训练集和测试集h5文件的方法

import h5py
import numpy as np

def load_data():
    train_data = h5py.File('../input/dataset/train_catvnoncat.h5', 'r')
    train_set_x = np.array(train_data['train_set_x'][:]) # train features
    train_set_y = np.array(train_data['train_set_y'][:]) # train labels

    test_data = h5py.File('../input/dataset/test_catvnoncat.h5', 'r')
    test_set_x = np.array(test_data['test_set_x'][:]) # test features
    test_set_y = np.array(test_data['test_set_y'][:]) # test labels

    classes = np.array(test_data["list_classes"][:]) # the list of classes

    train_set_y = train_set_y.reshape(-1, 1)
    test_set_y = test_set_y.reshape(-1, 1)

    print('train_x', train_set_x.shape, 'test_x', test_set_x.shape)
    print('train_y', train_set_y.shape, 'test_y', test_set_y.shape)

    return train_set_x, train_set_y, test_set_x, test_set_y, classes

降维输入特征数据并归一化

# 对输入数据进行降维
train_x_flatten = train_set_x.reshape(train_set_x.shape[0], -1)
test_x_flatten = test_set_x.reshape(test_set_x.shape[0], -1)

# 标准化输入数据
train_set_x = train_x_flatten/255
test_set_x = test_x_flatten/255

print('train_x', train_set_x.shape, 'test_x', test_set_x.shape)
print('train_y', train_set_y.shape, 'test_y', test_set_y.shape)
train_x (209, 12288) test_x (50, 12288)
train_y (209, 1) test_y (50, 1)

定义 batch 函数

def next_batch(X, Y, size, ind = None):
    '''
    Arguments:
    X -- 标准化后的 X 矩阵，shape 为 (number of examples, img_size)
    Y -- 一个由 0， 1 组成(其中 0 表示 non-cat, 1 表示 cat)的列向量, shape 为 (number of examples, 1)
    size -- 批量处理数据的数量
    ind -- 批量开始索引

    Returns:
    batch_x -- 一个 X 的 batch
    batch_y -- 一个 Y 的 batch
    '''
    if ind == None:
        indexes = np.random.choice(len(X), size=size)
        np.random.shuffle(indexes);
    else:
        indexes = np.arange(ind*size, np.where((ind+1) * size < len(X), (ind+1) * size, len(X)))

    batch_x = X[indexes]
    batch_y = Y[indexes]

    return batch_x, batch_y

定义张量及计算图

# 定义训练集大小，图片维度大小
num_examples = train_set_x.shape[0]
img_size = train_set_x.shape[1]

# 定义学习率
learning_rate = 0.002

# 初始化 x, y 占位符
x = tf.placeholder(tf.float32, [None, img_size])
y = tf.placeholder(tf.float32, [None, 1])

# 初始化 w, b 参数变量
# W = tf.Variable(tf.zeros([img_size, 1]))
# b = tf.Variable(tf.zeros([1]))
W = tf.Variable(tf.random_normal([img_size, 1]))
b = tf.Variable(tf.random_normal([1]))

# 前向传播计算预测值
logits = tf.matmul(x, W) + b
y_ = tf.sigmoid(logits)

# 计算代价函数
# cost = tf.reduce_mean(-1 * (y * tf.log(y_) + (1 - y) * tf.log(1 - y_))) # 计算溢出导致 cost 为 nan
cost = tf.reduce_mean(tf.nn.sigmoid_cross_entropy_with_logits(logits = logits, labels = y))

# 反向传播 梯度下降 优化 w, b 参数
optimizer = tf.train.GradientDescentOptimizer(learning_rate=learning_rate).minimize(cost)

# 计算模型预测结果
y_predict = tf.where(tf.greater(y_, np.full_like(y_, 0.5)), tf.zeros_like(y_), tf.ones_like(y_))

# 计算准确率
accuracy = 100 - tf.reduce_mean(tf.cast(tf.equal(y_predict, y), tf.float32)) * 100

训练模型

# 定义其他参数
batch_size = 30
iter_num = 6000
display_epoch = 500

# 初始化参数
init = tf.global_variables_initializer()

# 启动图 (graph)
sess = tf.Session()
sess.run(init)

# 迭代训练，记录损失值和准确度
cost_history = []
train_acc = []
test_acc = []

for epoch in range(iter_num):
    avg_cost = 0.
    avg_acuu = 0.
    total_batch = int(num_examples/batch_size)

    # 循环所有 batch
    for i in range(total_batch):
        batch_xs, batch_ys = next_batch(train_set_x, train_set_y, batch_size, i)

        # 运行优化器,计算代价
        _, c, a = sess.run([optimizer, cost, accuracy], feed_dict = {x: batch_xs, y: batch_ys})
        # 累积平均成本
        avg_cost += c / total_batch
        avg_acuu += a / total_batch

    # 记录每个迭代成本、准确率
    cost_history.append(avg_cost)
    train_acc.append(avg_acuu)
    test_acc.append(sess.run(accuracy, {x: test_set_x, y: test_set_y}))

    # 打印成本、准确率
    if (epoch+1) % display_epoch == 0:
        print('Epoch:', '%04d' % (epoch+1),
              'cost=', '{:.9f}'.format(cost_history[-1]),
              'train_acc=', '{:.2f}%'.format(train_acc[-1]),
              'test_acc=', '{:.2f}%'.format(test_acc[-1]),
             )

print('Optimization Finished!')

# 输出优化后的权重、偏差、准确率
print('\nAccuracy:', '{:.2f}%'.format(test_acc[-1]), '\nWeight', sess.run(W).flatten(), '\nBias', sess.run(b).flatten())

sess.close()

Epoch: 0500 cost= 2.338835160 train_acc= 67.78% test_acc= 64.00%
Epoch: 1000 cost= 1.171330139 train_acc= 84.44% test_acc= 68.00%
Epoch: 1500 cost= 0.600112927 train_acc= 91.11% test_acc= 70.00%
Epoch: 2000 cost= 0.311668488 train_acc= 96.11% test_acc= 66.00%
Epoch: 2500 cost= 0.145401367 train_acc= 97.78% test_acc= 68.00%
Epoch: 3000 cost= 0.078871274 train_acc= 98.89% test_acc= 66.00%
Epoch: 3500 cost= 0.050911599 train_acc= 99.44% test_acc= 66.00%
Epoch: 4000 cost= 0.037607569 train_acc= 99.44% test_acc= 64.00%
Epoch: 4500 cost= 0.029192524 train_acc= 99.44% test_acc= 64.00%
Epoch: 5000 cost= 0.023540985 train_acc= 99.44% test_acc= 64.00%
Epoch: 5500 cost= 0.019640291 train_acc= 100.00% test_acc= 64.00%
Epoch: 6000 cost= 0.016851171 train_acc= 100.00% test_acc= 64.00%
Optimization Finished!

Accuracy: 64.00%
Weight [-1.3992907   0.5485633  -0.13500667 ...  0.9261457   1.6744033
 -0.507459  ]
Bias [-0.33652216]

绘制模型评估曲线

# 绘制损失和准确度曲线
plt.plot(cost_history, 'k-')
plt.title('Loss per Generation')
plt.xlabel('Generation')
plt.ylabel('Loss')
plt.show()

# 绘制训练集、测试集准确率曲线
plt.plot(train_acc, 'k-', label='Train Set Accuracy')
plt.plot(test_acc, 'r--', label='Test Set Accuracy')
plt.title('Train and Test Accuracy')
plt.xlabel('Generation')
plt.ylabel('Accuracy')
plt.legend(loc='lower right')
plt.show()

第四章使用 Keras 实现深度神经网络进行猫咪识别

导入所需的package

from keras.models import Sequential
from keras.layers import Dense
from keras.optimizers import SGD
import numpy as np
import matplotlib.pyplot as plt
from loadH5File import load_data
from PIL import Image

%matplotlib inline
Using TensorFlow backend.

加载数据集 (cat / non-cat)

train_set_x, train_set_y, test_set_x, test_set_y, classes = load_data()

train_x (209, 64, 64, 3) test_x (50, 64, 64, 3)
train_y (209, 1) test_y (50, 1)

降维输入特征数据并归一化

# 偏平化输入特征
train_x_flatten = train_set_x.reshape(train_set_x.shape[0], -1)
test_x_flatten = test_set_x.reshape(test_set_x.shape[0], -1)

# 标准化输入数据
train_set_x = train_x_flatten/255
test_set_x = test_x_flatten/255

print('train_x', train_set_x.shape, 'test_x', test_set_x.shape)
print('train_y', train_set_y.shape, 'test_y', test_set_y.shape)
train_x (209, 12288) test_x (50, 12288)
train_y (209, 1) test_y (50, 1)

搭建深度神经网络

# 定义训练集大小，图片维度大小
num_examples = train_set_x.shape[0]
img_size = train_set_x.shape[1]

model = Sequential()
model.add(Dense(256, activation="relu", input_shape=(img_size,)))
model.add(Dense(128, activation="relu"))
model.add(Dense(64, activation="relu"))
model.add(Dense(32, activation="relu"))
model.add(Dense(1, activation="sigmoid"))

查看神经网络

model.summary()
_________________________________________________________________
Layer (type)                 Output Shape              Param #
=================================================================
dense_1 (Dense)              (None, 256)               3145984
_________________________________________________________________
dense_2 (Dense)              (None, 128)               32896
_________________________________________________________________
dense_3 (Dense)              (None, 64)                8256
_________________________________________________________________
dense_4 (Dense)              (None, 32)                2080
_________________________________________________________________
dense_5 (Dense)              (None, 1)                 33
=================================================================
Total params: 3,189,249
Trainable params: 3,189,249
Non-trainable params: 0
_________________________________________________________________

编译模型

model.compile(optimizer=SGD(), loss="binary_crossentropy", metrics=['accuracy'])

开始训练

history = model.fit(train_set_x, train_set_y, epochs=20, validation_data=(test_set_x, test_set_y), verbose=1)

Train on 209 samples, validate on 50 samples
Epoch 1/20
209/209 [==============================] - 1s 4ms/step - loss: 0.6918 - acc: 0.5789 - val_loss: 0.8544 - val_acc: 0.3400
Epoch 2/20
209/209 [==============================] - 0s 645us/step - loss: 0.6483 - acc: 0.6459 - val_loss: 0.8409 - val_acc: 0.3400
Epoch 3/20
209/209 [==============================] - 0s 647us/step - loss: 0.6270 - acc: 0.6507 - val_loss: 0.9070 - val_acc: 0.3400
Epoch 4/20
209/209 [==============================] - 0s 721us/step - loss: 0.6206 - acc: 0.6507 - val_loss: 0.9309 - val_acc: 0.3400
Epoch 5/20
209/209 [==============================] - 0s 645us/step - loss: 0.6367 - acc: 0.6651 - val_loss: 0.9284 - val_acc: 0.3400
Epoch 6/20
209/209 [==============================] - 0s 609us/step - loss: 0.6073 - acc: 0.6555 - val_loss: 0.9694 - val_acc: 0.3400
Epoch 7/20
209/209 [==============================] - 0s 646us/step - loss: 0.6028 - acc: 0.6555 - val_loss: 0.8310 - val_acc: 0.3400
Epoch 8/20
209/209 [==============================] - 0s 633us/step - loss: 0.5790 - acc: 0.6842 - val_loss: 0.7948 - val_acc: 0.3400
Epoch 9/20
209/209 [==============================] - 0s 605us/step - loss: 0.5653 - acc: 0.7081 - val_loss: 0.7247 - val_acc: 0.3600
Epoch 10/20
209/209 [==============================] - 0s 694us/step - loss: 0.5807 - acc: 0.6842 - val_loss: 0.9499 - val_acc: 0.3400
Epoch 11/20
209/209 [==============================] - 0s 704us/step - loss: 0.5729 - acc: 0.7129 - val_loss: 0.6200 - val_acc: 0.8000
Epoch 12/20
209/209 [==============================] - 0s 668us/step - loss: 0.5491 - acc: 0.7703 - val_loss: 0.6280 - val_acc: 0.7400
Epoch 13/20
209/209 [==============================] - 0s 678us/step - loss: 0.5316 - acc: 0.7321 - val_loss: 0.7044 - val_acc: 0.5800
Epoch 14/20
209/209 [==============================] - 0s 671us/step - loss: 0.4940 - acc: 0.8086 - val_loss: 0.8441 - val_acc: 0.3600
Epoch 15/20
209/209 [==============================] - 0s 747us/step - loss: 0.5148 - acc: 0.7416 - val_loss: 0.7896 - val_acc: 0.3400
Epoch 16/20
209/209 [==============================] - 0s 730us/step - loss: 0.4917 - acc: 0.7990 - val_loss: 0.6306 - val_acc: 0.7200
Epoch 17/20
209/209 [==============================] - 0s 723us/step - loss: 0.5081 - acc: 0.8134 - val_loss: 0.6794 - val_acc: 0.5600
Epoch 18/20
209/209 [==============================] - 0s 683us/step - loss: 0.5363 - acc: 0.7081 - val_loss: 1.0372 - val_acc: 0.3400
Epoch 19/20
209/209 [==============================] - 0s 725us/step - loss: 0.4456 - acc: 0.8038 - val_loss: 0.5148 - val_acc: 0.7800
Epoch 20/20
209/209 [==============================] - 0s 719us/step - loss: 0.4556 - acc: 0.8278 - val_loss: 0.7439 - val_acc: 0.4800

绘制训练曲线

# 绘制训练 & 验证的损失值
plt.plot(history.history['loss'])
plt.plot(history.history['val_loss'])
plt.title('Loss per Generation')
plt.ylabel('Loss')
plt.xlabel('Generation')
plt.legend(['Train', 'Test'], loc='upper left')
plt.show()

# 绘制训练 & 验证的准确率值
plt.plot(history.history['acc'])
plt.plot(history.history['val_acc'])
plt.title('Train and Test Accuracy')
plt.ylabel('Accuracy')
plt.xlabel('Generation')
plt.legend(['Train', 'Test'], loc='upper left')
plt.show()

总结

在实战中，我们可以很明显的观察到，准确率在达到一个阈值后就无法再提升了，我们通常把这种情况称为过拟合，这是拟合高方差的结果。为此可以采取一系列措施解决，如 L2正则、随机失活、数据扩增、提前结束迭代训练等等，这些是在调整神经网络模型中常用的方法，这里不再详述。

相信大家通过阅读，已经大概了解神经网络的基础，以及了解如何实现一个神经网络，Tensorflow、Keras的使用和体验。在机器学习框架的选择上，个人建议可以考虑 Keras 这个更高阶的框架，十分适合初学者。

只有不断编程实战才能加强神经网络建模和参数优化的能力，希望感兴趣的同学看过这篇文章可以有所得，谢谢大家。

作者介绍：
江伯（企业代号名），目前负责贝壳找房经纪人作业和横向技术相关工作。

本文转载自公众号贝壳产品技术（ID：gh_9afeb423f390）。

原文链接：

https://mp.weixin.qq.com/s/THlhGRKC5tfF2XxRNcIoZg

创作场景

与 DeepLearning 的初次接触（下）
