一. DC-ASGD算法介绍

此前，和大家也一起讨论过DC-ASGD算法，详细可见：https://zhuanlan.zhihu.com/p/80978479

DC-ASGD算法主要解决的问题是：异步的随机梯度下降法（ASGD）在深度学习模型的训练中会存在delayed gradients的问题，就是当一个worker向参数server端提交它算出的梯度时，server端其实已经被其它worker更新过好多次了。主要解决方案是利用梯度项的泰勒展开式去近似逼近loss函数的Hessian矩阵。

具体算法：

二. DC-ASGD算法tensorflow实现

那么如何在tensorflow中实现dc-asgd算法呢？在上一篇文章中，我们讨论过tensorflow中Optimizer类的源码解析，其实就是为该篇文章做铺垫。接下来我们就具体分析下Optimizer的子类-DelayCompensatedGradientDescentOptimizer类。

"""DelayCompensatedGradientDescentOptimizer for TensorFlow."""
from __future__ import absolute_import
from __future__ import division
from __future__ import print_function

from tensorflow.python.framework import ops
from tensorflow.python.ops import array_ops
from tensorflow.python.ops import control_flow_ops
from tensorflow.python.ops import math_ops
from tensorflow.python.ops import state_ops
from tensorflow.python.training import optimizer
from tensorflow.python.training import training_ops

GATE_NONE = 0
GATE_OP = 1
GATE_GRAPH = 2


class DelayCompensatedGradientDescentOptimizer(optimizer.Optimizer):
    """Optimizer that implements the DelayCompensatedGradientDescent algorithm.
    See Zheng, Shuxin, et al., 2016
    (pdf).
    """

    def __init__(self, learning_rate, variance_parameter=2.0, num_workers=1,
                 use_locking=False, name="DelayCompensatedGradientDescentOptimizer"):

        """Construct a gradient descent optimizer with delay compensation.
        It is cricial to note the `num_workers` in constructor and `worker_index` in
        `minimize()` and `apply_gradients()`.
        Contrast to AdaMaxamOptimizer, the sparse implementation of this algorithm
        (used when the gradient is an IndexedSlices object, typically because of
        `tf.gather` or an embedding lookup in the forward pass) only updates
        variable slices and corresponding `shadow_t` term when that part of
        the variable was used in the forward pass. This means that the sparse
        behavior is contrast to the dense behavior (similar to some momentum
        implementations which ignore momentum unless a variable slice was actually
        used).
        Args:
          learning_rate: A Tensor or a floating point value. The learning rate.
          variance_parameter: A Tensor or a floating point value.
            The variance control parameter.
          num_workers: A int value. The number of workers.
          use_locking: If True use locks for update operations.
          name: Optional name for the operations created when applying gradients.
            Defaults to "DelayCompensatedGradientDescentOptimizer".
        """
        num_workers = self._call_if_callable(num_workers)
        if num_workers <= 0:
            raise ValueError("num_workers must be positive: %s" % num_workers)
        super(DelayCompensatedGradientDescentOptimizer, self).__init__(use_locking, name)
        self._lr = learning_rate
        self._lambda = variance_parameter
        self._num_workers = num_workers
        self._learning_rate_tensor = None
        self._lambda_tensor = None
        self._use_locking = use_locking

    def _create_slots(self, var_list):
        for index in range(self._num_workers):
            for v in var_list:
                self._zeros_slot(v, "shadow_{0}".format(index), self._name)

    def _prepare(self):
        lr = self._call_if_callable(self._lr)
        lambda_ = self._call_if_callable(self._lambda)

        self._learning_rate_tensor = ops.convert_to_tensor(lr, name="learning_rate")
        self._lambda_tensor = ops.convert_to_tensor(lambda_, name="lambda")

    def _apply_dense(self, grad, var):

        shadow = self.get_slot(var, "shadow_{0}".format(self.worker_index))
        return training_ops.apply_delay_compensated_gradient_descent(
            var,
            math_ops.cast(self._learning_rate_tensor, grad.dtype.base_dtype),
            grad,
            math_ops.cast(self._lambda_tensor, grad.dtype.base_dtype),
            shadow,
            use_locking=self._use_locking).op

    def _resource_apply_dense(self, grad, var):

        shadow = self.get_slot(var, "shadow_{0}".format(self.worker_index))
        return training_ops.resource_apply_delay_compensated_gradient_descent(
            var.handle,
            math_ops.cast(self._learning_rate_tensor, grad.dtype.base_dtype),
            grad,
            math_ops.cast(self._lambda_tensor, grad.dtype.base_dtype),
            shadow.handle,
            use_locking=self._use_locking)

    def _apply_sparse_shared(self, grad, var, indices):

        shadow = self.get_slot(var, "shadow_{0}".format(self.worker_index))
        # if shadow is None:
        #   raise ValueError("None shadow with index = " + str(self.worker_index) + " and var = " + str(var))
        lambda_ = math_ops.cast(self._lambda_tensor, var.dtype.base_dtype)
        lr = math_ops.cast(self._learning_rate_tensor, var.dtype.base_dtype)

        var_slice = array_ops.gather(var, indices)
        shadow_slice = array_ops.gather(shadow, indices)

        var_scaled_g_values = lr * (grad + lambda_ * grad * grad * (var_slice - shadow_slice))

        var_t = state_ops.scatter_add(var, indices, -var_scaled_g_values, use_locking=self._use_locking)

        with ops.control_dependencies([var_t]):
            shadow_t = state_ops.assign(shadow, var_t)

        return control_flow_ops.group(*[var_t, shadow_t])

    def _apply_sparse(self, grad, var):
        return self._apply_sparse_shared(
            grad.values, var, grad.indices)

    def _resource_apply_sparse(self, grad, var, indices):
        return self._apply_sparse_shared(
            grad, var, indices)

    def minimize(self, loss, global_step=None, var_list=None,
                 gate_gradients=GATE_OP, aggregation_method=None,
                 colocate_gradients_with_ops=False, name=None,
                 grad_loss=None, worker_index=0):
        self.worker_index = worker_index
        return super(DelayCompensatedGradientDescentOptimizer, self).minimize(loss=loss, global_step=global_step,
                                                                              var_list=var_list,
                                                                              gate_gradients=gate_gradients,
                                                                              aggregation_method=aggregation_method,
                                                                              colocate_gradients_with_ops=colocate_gradients_with_ops,
                                                                              name=name,
                                                                              grad_loss=grad_loss)

    def apply_gradients(self, grads_and_vars, global_step=None, name=None, worker_index=0):
        self.worker_index = worker_index
        return super(DelayCompensatedGradientDescentOptimizer, self).apply_gradients(grads_and_vars=grads_and_vars,

                                                                                 global_step=global_step, name=name)

_create_slots函数用来创建一些额外的参数，这里创建的是每一个worker上的每一个variable所对应的备份变量shadow。_prepare函数用来准备优化器的常规超参数。

我们重点关注下_apply_sparse函数，该函数调用的是_apply_sparse_shared函数，参数grad的数据类型是IndexedSlices类型，那么什么是IndexedSlices类型呢？这里Slice的意思是从Tensor里面取特定的一些下标得到原先tensor变量的一部分，比如说原来的tensor的shape是[10,10]，取下标[0]得到一个[10]的Tensor，这个Tensor就是原Tensor的一个Slice。那么IndexedSlices其实就是一堆Slices和它们所对应的下标（也就是Index）。在梯度更新过程中，如果只需要更新某几行的梯度值，就可以将梯度表示成这种数据结构，来节省计算资源。

所以_apply_sparse_shared函数参数传入的是grad.values和grad.indices，分别表示特定行的梯度值和行的下标。在计算梯度项时：var_scaled_g_values = lr *(grad + lambda_ * grad * grad *(var_slice - shadow_slice))，也需要先求出特定行的var_slice和shadow_slice。然后根据求出的梯度项更新参数时：var_t = state_ops.scatter_add(var, indices,-var_scaled_g_values, use_locking=self._use_locking)，也是在特定的那些行（根据indices确定的）做更新。

当这一轮的参数做完更新后，需要将当前时刻的变量var_t备份一下，以用于下一时刻的参数更新：shadow_t = state_ops.assign(shadow, var_t)。最后将var_t, shadow_t的更新操作放进control_flow_ops中。

我们举一个简单的example来说明一下这种IndexedSlices类型的梯度是怎么更新的：

import numpy as np
import tensorflow as tf
from tensorflow.python.framework import constant_op
from tensorflow.python.framework import ops
from tensorflow.python.ops import variables
from tensorflow.python.training import adam


if __name__ == '__main__':
    value_a = np.ones(shape=[3, 10])
    indices_a = np.array([0, 3, 8])
    dense_shape_a = [10, 10]
    grad_slices_a = ops.IndexedSlices(constant_op.constant(value_a), constant_op.constant(indices_a),
                                      constant_op.constant(dense_shape_a))

    var_np = np.ones(shape=[10, 10])

    var0 = variables.RefVariable(var_np)
    opt = adam.AdamOptimizer()
    update = opt.apply_gradients(zip([grad_slices_a], [var0]))
    # variables.global_variables_initializer().run()
    sess = tf.Session()
    sess.run(tf.global_variables_initializer())
    print("initial variable is:", sess.run(var0))
    sess.run(update)
    print("update 1 time variable is:", sess.run(var0))


输出：
initial variable is: [[1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]
 [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]
 [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]
 [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]
 [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]
 [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]
 [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]
 [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]
 [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]
 [1. 1. 1. 1. 1. 1. 1. 1. 1. 1.]]
update 1 time variable is: [[0.999 0.999 0.999 0.999 0.999 0.999 0.999 0.999 0.999 0.999]
 [1.    1.    1.    1.    1.    1.    1.    1.    1.    1.   ]
 [1.    1.    1.    1.    1.    1.    1.    1.    1.    1.   ]
 [0.999 0.999 0.999 0.999 0.999 0.999 0.999 0.999 0.999 0.999]
 [1.    1.    1.    1.    1.    1.    1.    1.    1.    1.   ]
 [1.    1.    1.    1.    1.    1.    1.    1.    1.    1.   ]
 [1.    1.    1.    1.    1.    1.    1.    1.    1.    1.   ]
 [1.    1.    1.    1.    1.    1.    1.    1.    1.    1.   ]
 [0.999 0.999 0.999 0.999 0.999 0.999 0.999 0.999 0.999 0.999]
 [1.    1.    1.    1.    1.    1.    1.    1.    1.    1.   ]]

可以很清楚地看到，执行一次梯度更新之后，只有0，3，8这三行的变量值发生了改变。这就是使用IndexedSlices类型的优势。

另外，training_ops.apply_delay_compensated_gradient_descent这个函数是在tensorflow/core/kernels/training_ops.cc中实现的，核心代码如下：

template <typename T>
struct ApplyDelayCompensatedGradientDescent<CPUDevice, T> {
  void operator()(const CPUDevice& d, typename TTypes<T>::Flat var,
                   typename TTypes<T>::ConstScalar lr,
                   typename TTypes<T>::ConstFlat grad,
                   typename TTypes<T>::ConstScalar variance,
                   typename TTypes<T>::Flat shadow) {
    var.device(d) -= lr() * (grad + variance() * grad * grad * (var - shadow));
    shadow.device(d) = var;
  }
};

其实除了这两个文件之外，还需要写一下注册ApplyDelayCompensatedGradientDescent的OP接口，这里就不详细讲解了。

三.如何使用DC-ASGD算法

在tensorflow源码目录中修改或添加完dc-asgd算法的几个相关文件后，需要重新编译一下tensorflow。编译成功后，就可以愉快地使用dc-asgd算法的接口啦。

下面给大家举一个使用DelayCompensatedGradientDescentOptimizer优化器的分布式训练demo：

from __future__ import print_function, absolute_import, division

import tensorflow as tf

tf.app.flags.DEFINE_string("ps_hosts", "localhost:2222", "ps hosts")
tf.app.flags.DEFINE_string("worker_hosts", "localhost:2223,localhost:2224", "worker hosts")
tf.app.flags.DEFINE_string("job_name", "worker", "'ps' or'worker'")
tf.app.flags.DEFINE_integer("task_index", 0, "Index of task within the job")
tf.app.flags.DEFINE_integer("num_workers", 2, "Number of workers")
tf.app.flags.DEFINE_boolean("is_sync", False, "using synchronous training or not")

FLAGS = tf.app.flags.FLAGS


def model(images):
    """Define a simple mnist classifier"""
    net = tf.layers.dense(images, 500, activation=tf.nn.relu)
    net = tf.layers.dense(net, 500, activation=tf.nn.relu)
    net = tf.layers.dense(net, 10, activation=None)
    return net


(x_train, y_train), (x_test, y_test) = tf.keras.datasets.mnist.load_data()
x_train = x_train.reshape(-1, 784).astype('float32')
x_test = x_test.reshape(-1, 784).astype('float32')
x_train /= 255
x_test /= 255


def get_batch(image, label, batch_size=32, training=True):
    df = tf.data.Dataset.from_tensor_slices((image, label))
    if training:
        df = df.repeat(10).shuffle(buffer_size=1000)
    df = df.batch(batch_size).prefetch(batch_size)
    iterator = df.make_one_shot_iterator()
    batch_x, batch_y = iterator.get_next()
    return batch_x, batch_y


def main(_):
    ps_hosts = FLAGS.ps_hosts.split(",")
    worker_hosts = FLAGS.worker_hosts.split(",")

    # create the cluster configured by `ps_hosts' and 'worker_hosts'
    cluster = tf.train.ClusterSpec({"ps": ps_hosts, "worker": worker_hosts})

    # create a server for local task
    server = tf.train.Server(cluster, job_name=FLAGS.job_name, task_index=FLAGS.task_index)

    train_batch_x, train_batch_y = get_batch(x_train, y_train)
    test_batch_x, test_batch_y = get_batch(x_test, y_test, training=False)

    if FLAGS.job_name == "ps":
        server.join()  # ps hosts only join
    elif FLAGS.job_name == "worker":
        # workers perform the operation
        # ps_strategy = tf.contrib.training.GreedyLoadBalancingStrategy(FLAGS.num_ps)

        # Note: tf.train.replica_device_setter automatically place the paramters (Variables)
        # on the ps hosts (default placement strategy:  round-robin over all ps hosts, and also
        # place multi copies of operations to each worker host
        with tf.device(tf.train.replica_device_setter(worker_device="/job:worker/task:%d" % FLAGS.task_index,
                                                      cluster=cluster)):

            logits = model(train_batch_x)
            loss = tf.reduce_mean(
                tf.nn.softmax_cross_entropy_with_logits(logits=logits, labels=tf.one_hot(train_batch_y, 10)))

            # The StopAtStepHook handles stopping after running given steps.
            hooks = [tf.train.StopAtStepHook(last_step=10000)]

            global_step = tf.train.get_or_create_global_step()
            #optimizer = tf.train.AdamOptimizer(learning_rate=1e-04)
            optimizer = tf.contrib.opt.DelayCompensatedGradientDescentOptimizer(learning_rate=0.001)

            if FLAGS.is_sync:
                # asynchronous training
                # use tf.train.SyncReplicasOptimizer wrap optimizer
                # ref: https://www.tensorflow.org/api_docs/python/tf/train/SyncReplicasOptimizer
                optimizer = tf.train.SyncReplicasOptimizer(optimizer, replicas_to_aggregate=FLAGS.num_workers,
                                                           total_num_replicas=FLAGS.num_workers)
                # create the hook which handles initialization and queues
                hooks.append(optimizer.make_session_run_hook((FLAGS.task_index == 0)))

            train_op = optimizer.minimize(loss, global_step=global_step)

            # The MonitoredTrainingSession takes care of session initialization,
            # restoring from a checkpoint, saving to a checkpoint, and closing when done
            # or an error occurs.
            with tf.train.MonitoredTrainingSession(master=server.target,
                                                   is_chief=(FLAGS.task_index == 0),
                                                   checkpoint_dir="./checkpoint_dir",
                                                   hooks=hooks) as mon_sess:
                while not mon_sess.should_stop():
                    # mon_sess.run handles AbortedError in case of preempted PS.
                    _, ls, step = mon_sess.run([train_op, loss, global_step])
                    if step % 100 == 0:
                        print("Train step %d, loss: %f" % (step, ls))


if __name__ == "__main__":
    tf.app.run()

启动命令是：

python dc_asgd_exp.py --ps_hosts=localhost:2222 --worker_hosts=localhost:2224 --job_name=ps --task_index=0
python dc_asgd_exp.py --ps_hosts=localhost:2222 --worker_hosts=localhost:2224 --job_name=worker --task_index=0

参考文献：

https://zhuanlan.zhihu.com/p/80978479
https://zhuanlan.zhihu.com/p/87348147
https://www.zhihu.com/question/277403551
https://zhuanlan.zhihu.com/p/35083779

本文转载自Alex-zhai知乎账号。

原文链接：https://www.zhihu.com/people/alex-zhai-19/posts

创作场景

tensorflow 中 ASGD with Delay Compensation 优化器代码实现
