Redis Sentinel 是 Redis 提供的高可用模型解决方案。Sentinel 可以自动监测一个或多个 Redis 主备实例,并在主实例宕机的情况下自动实行主备倒换。本系列通过作者对 RedisSentinel 代码的理解,详细说明 Sentinel 的代码实现方式。
Sentinel 使用 Redis 内核相同的事件驱动代码框架,但 Sentinel 有自己独特的初始化步骤。在这篇文章里,作者会介绍 Sentinel 与 Redis 服务器不同的初始化部分。
我们可以通过 redis-sentinel 或者 redis-server--sentinel 这两种方式启动并运行 Sentinel 实例,这两种方式是等价的。在 Redis server.c 的 main 函数中,我们会看到 Redis 如何判断用户指定以 Sentinel 方式运行的逻辑:
int main(int argc, char **argv) {
..........
server.sentinel_mode = checkForSentinelMode(argc,argv);
..........
}
其中 checkForSentinelMode 函数会监测以下两种条件:
程序使用 redis-sentinel 可执行文件执行。
程序参数列表中有–sentinel 标志。
以上任何一种条件成立则 Redis 会使用 Sentinel 的方式运行。
/* Returns 1 if there is --sentinel among the arguments or if
* argv[0] contains "redis-sentinel". */
int checkForSentinelMode(int argc, char **argv) {
int j;
if (strstr(argv[0],"redis-sentinel") != NULL) return 1;
for (j = 1; j < argc; j++)
if (!strcmp(argv[j],"--sentinel")) return 1;
return 0;
}
在 Redis 判断是否以 Sentinel 的方式运行以后,我们会看到如下代码段:
int main(int argc, char **argv) {
struct timeval tv;
int j;
............
/* We need to init sentinel right now as parsing the configuration file
* in sentinel mode will have the effect of populating the sentinel
* data structures with master nodes to monitor. */
if (server.sentinel_mode) {
initSentinelConfig();
initSentinel();
}
............
在 initSentinelConfig 函数中,会使用 Sentinel 特定的端口(默认为 26379)来替代 Redis 的默认端口(6379)。另外,在 Sentinel 模式下,需要禁用服务器运行保护模式。
/* This function overwrites a few normal Redis config default with Sentinel
* specific defaults. */
void initSentinelConfig(void) {
server.port = REDIS_SENTINEL_PORT;
server.protected_mode = 0; /* Sentinel must be exposed. */
}
与此同时,initSentinel 函数会做如下操作:
/* Perform the Sentinel mode initialization. */
void initSentinel(void) {
unsigned int j;
/* Remove usual Redis commands from the command table, then just add
* the SENTINEL command. */
dictEmpty(server.commands,NULL);
for (j = 0; j < sizeof(sentinelcmds)/sizeof(sentinelcmds[0]); j++) {
int retval;
struct redisCommand *cmd = sentinelcmds+j;
retval = dictAdd(server.commands, sdsnew(cmd->name), cmd);
serverAssert(retval == DICT_OK);
/* Translate the command string flags description into an actual
* set of flags. */
if (populateCommandTableParseFlags(cmd,cmd->sflags) == C_ERR)
serverPanic("Unsupported command flag");
}
/* Initialize various data structures. */
sentinel.current_epoch = 0;
sentinel.masters = dictCreate(&instancesDictType,NULL);
sentinel.tilt = 0;
sentinel.tilt_start_time = 0;
sentinel.previous_time = mstime();
.............
}
使用 Sentinel 自带的命令表去替代 Redis 服务器原生的命令. Sentinel 支持的命令表如下:
struct redisCommand sentinelcmds[] = {
{"ping",pingCommand,1,"",0,NULL,0,0,0,0,0},
{"sentinel",sentinelCommand,-2,"",0,NULL,0,0,0,0,0},
{"subscribe",subscribeCommand,-2,"",0,NULL,0,0,0,0,0},
{"unsubscribe",unsubscribeCommand,-1,"",0,NULL,0,0,0,0,0},
{"psubscribe",psubscribeCommand,-2,"",0,NULL,0,0,0,0,0},
{"punsubscribe",punsubscribeCommand,-1,"",0,NULL,0,0,0,0,0},
{"publish",sentinelPublishCommand,3,"",0,NULL,0,0,0,0,0},
{"info",sentinelInfoCommand,-1,"",0,NULL,0,0,0,0,0},
{"role",sentinelRoleCommand,1,"ok-loading",0,NULL,0,0,0,0,0},
{"client",clientCommand,-2,"read-only no-script",0,NULL,0,0,0,0,0},
{"shutdown",shutdownCommand,-1,"",0,NULL,0,0,0,0,0},
{"auth",authCommand,2,"no-auth no-script ok-loading ok-stale fast",0,NULL,0,0,0,0,0},
{"hello",helloCommand,-2,"no-auth no-script fast",0,NULL,0,0,0,0,0}
};
初始化 Sentinel 主状态结构,Sentinel 主状态的定义及注释如下。
/* Main state. */
struct sentinelState {
char myid[CONFIG_RUN_ID_SIZE+1]; /* This sentinel ID. */
uint64_t current_epoch; /* Current epoch. */
dict *masters; /* Dictionary of master sentinelRedisInstances.
Key is the instance name, value is the
sentinelRedisInstance structure pointer. */
int tilt; /* Are we in TILT mode? */
int running_scripts; /* Number of scripts in execution right now. */
mstime_t tilt_start_time; /* When TITL started. */
mstime_t previous_time; /* Last time we ran the time handler. */
list *scripts_queue; /* Queue of user scripts to execute. */
char *announce_ip; /* IP addr that is gossiped to other sentinels if
not NULL. */
int announce_port; /* Port that is gossiped to other sentinels if
non zero. */
unsigned long simfailure_flags; /* Failures simulation. */
int deny_scripts_reconfig; /* Allow SENTINEL SET ... to change script
paths at runtime? */
} sentinel;
其中 masters 字典指针中的每个值都对应着一个 Sentinel 检测的主实例。
在读取配置信息后,Redis 服务器主函数会调用 sentinelIsRunning 函数, 做以下几个工作:
检查配置文件是否被设置,并且检查程序对配置文件是否有写权限,因为如果 Sentinel 状态改变的话,会不断将自己当前状态记录在配置文件中。
如果在配置文件中指定运行 ID,Sentinel 会使用这个 ID 作为运行 ID,相反地,如果没有指定运行 ID,Sentinel 会生成一个 ID 用来作为 Sentinel 的运行 ID。
对所有的 Sentinel 监测实例产生初始监测事件。
/* This function gets called when the server is in Sentinel mode, started,
* loaded the configuration, and is ready for normal operations. */
void sentinelIsRunning(void) {
int j;
if (server.configfile == NULL) {
serverLog(LL_WARNING,
"Sentinel started without a config file. Exiting...");
exit(1);
} else if (access(server.configfile,W_OK) == -1) {
serverLog(LL_WARNING,
"Sentinel config file %s is not writable: %s. Exiting...",
server.configfile,strerror(errno));
exit(1);
}
/* If this Sentinel has yet no ID set in the configuration file, we
* pick a random one and persist the config on disk. From now on this
* will be this Sentinel ID across restarts. */
for (j = 0; j < CONFIG_RUN_ID_SIZE; j++)
if (sentinel.myid[j] != 0) break;
if (j == CONFIG_RUN_ID_SIZE) {
/* Pick ID and persist the config. */
getRandomHexChars(sentinel.myid,CONFIG_RUN_ID_SIZE);
sentinelFlushConfig();
}
/* Log its ID to make debugging of issues simpler. */
serverLog(LL_WARNING,"Sentinel ID is %s", sentinel.myid);
/* We want to generate a +monitor event for every configured master
* at startup. */
sentinelGenerateInitialMonitorEvents();
}
本文转载自中间件小哥公众号。
原文链接:https://mp.weixin.qq.com/s/GWe3eBGrFcOmM5M0QYXHkQ
