GKE 上通过 Istio 控制微服务间流量

魏衡

  • 2020-11-03
  • 本文字数:5054 字

    阅读完需:约 17 分钟

GKE上通过Istio控制微服务间流量

Kubernetes 是容器的编排工具,可以非常方便的进行大规模的容器调度。通过这种模式,将传统的软件模式改造成微服务模式。这种微服务的架构模式,将复杂系统切分为数十乃至上百个小服务,每个服务负责实现一个独立的业务逻辑。这些小服务易于被小型的软件工程师团队负责,这带来了语言和框架选择灵活性,并可以缩短应用开发上线时间,可根据不同的工作负载和资源要求对服务进行独立缩扩容等优势。但另一方面,当应用被拆分为多个微服务进程后,进程内的方法调用变成了了进程间的远程调用。这就引入了对大量服务的连接、管理和监控的复杂性。


在微服务模式中,如何实现各个进程间的通信,是微服务中一个重要的部分。


Istio 是 CNCF 提出的由 Google、IBM、Lyft 等共同开源的 Service Mesh 框架。是连接 Kubernetes 和 Serverless 架构的重要基础设施层。

一 Istio 简介

1 Istio

Isito 主要实现以下三个功能:


1.监控


2.安全


3.流量管理


其架构图如下:



其中,Citadel 是服务间认证加密的组件,Pilot 是服务间通信策略的控制层面,Galley 负责检查用户的策略配置。


其中 Pilot 是数据层面的控制组件,Proxy 是数据层面的执行组件。

2 流量管理

根据前面的描述,我们知道,在 Istio 中,流量管理通过 Pilot 和 Envoy 实现。Pilot 对 Envoy 通过下面几个组件进行流量策略的控制:



1.Gateway - 是 Istio 的 IngressGateway,流量通过这个 Gateway 进入 VirtualService。


2.VirtualService - 通过


a.HTTP header


b.URIs


c.Ports


d.sourceLables


对流量进行分类,分发到不同的 Service 上。


3.DestinationRule -定义了流量如何分发到 Pod 上,比如负载均衡策略、Session Affinity 等。同时还可以通过 Label 对同一组服务进行更细致的分组,比如 ServiceA-v1、ServiceA-v2。用于流量的 splitting。


本文将介绍在 GKE 上如何实现通过 Isito 实现 service 间流量的控制。

二 环境准备

1 GKE

在 Google Cloud 上创建 GKE Cluster,enable Istio,具体命令行如下:


gcloud beta container clusters create "istiodemo" --zone "us-central1-c" --num-nodes "4" --enable-stackdriver-kubernetes --enable-ip-alias --addons HttpLoadBalancing,Istio

复制代码


通过 Console 界面查看创建的 GKE Cluster:



查看 Istio 相关的 workload:


2 本地安装 Istioctl 工具

本文采用 Istio1.4.3:


export ISTIO_VERSION=1.4.3curl -L https://git.io/getLatestIstio | ISTIO_VERSION=$ISTIO_VERSION sh -
复制代码


检查 Istio 版本


./istioctl version --short
client version: 1.4.3control plane version: 04871014b586f671f2ce14646e5061945f75c9c5data plane version: (1 proxies)
复制代码


查看 istio 状态:



这里采用 Istio 的 Demo profile,可以用下面的命令:


istioctl manifest apply --set profile=demo
复制代码


可以看到各种监控的工具都安装完成:


3 安装 bookinfo

Bookinfo 跟随 Istio 的安装包一起下载到本地目录。Bookinfo 的软件架构如下:



安装过程如下:


kubectl label namespace default istio-injection=enabledkubectl apply -f samples/bookinfo/platform/kube/bookinfo.yaml
复制代码


查看 pod、service 信息:



红框表示出来的,都是 bookinfo 相关的 deployment。



红框表示出来的,都是 bookinfo 相关的 service。


查看应用的状态:


kubectl exec -it $(kubectl get pod -l app=ratings \      -o jsonpath='{.items[0].metadata.name}') \      -c ratings -- curl productpage:9080/productpage \      | grep -o "<title>.*</title>"
复制代码


Simple Bookstore App

三 通过 Istio 进行流量管理

1 配置 Gateway 和 VirtualService 使外部可以访问

配置 Istio Ingress Gateway,使外部可以访问 bookinfo:


kubectl apply -f samples/bookinfo/networking/bookinfo-gateway.yaml
复制代码


配置文件如下:


apiVersion: networking.istio.io/v1alpha3kind: Gatewaymetadata: name: bookinfo-gatewayspec: selector:   istio: ingressgateway # use istio default controller servers: - port:     number: 80     name: http     protocol: HTTP   hosts:   - "*"---apiVersion: networking.istio.io/v1alpha3kind: VirtualServicemetadata: name: bookinfospec: hosts: - "*" gateways: - bookinfo-gateway http: - match:   - uri:       exact: /productpage   - uri:       prefix: /static   - uri:       exact: /login   - uri:       exact: /logout   - uri:       prefix: /api/v1/products   route:   - destination:       host: productpage       port:         number: 9080
复制代码


查看 GW 的公网地址:


kubectl get svc -n istio-systemNAME                     TYPE           CLUSTER-IP    EXTERNAL-IP                                                                                                                                          istio-citadel            ClusterIP      10.0.12.62    <none>                                                                                                                                    istio-galley             ClusterIP      10.0.5.255    <none>                                                                                                                           istio-ingressgateway     LoadBalancer   10.0.13.240   35.202.166.31     istio-pilot              ClusterIP      10.0.6.138    <none>                                                                                                                istio-policy             ClusterIP      10.0.2.42     <none>                                                                                                                          istio-sidecar-injector   ClusterIP      10.0.0.149    <none>                                                                                                                                             istio-telemetry          ClusterIP      10.0.15.195   <none>                                                                                                              promsd                   ClusterIP      10.0.5.191    <none>
复制代码


可以看到 istio-ingressgateway 的公网地址是 35.202.166.31。通过这个 IP 地址访问 bookinfo:


curl -s http://$Gateway_URL/productpage | grep -o "<title>.*</title>"

复制代码


Simple Bookstore App



通过 Kiali 界面 istioctl dashboard kiali: admin/admin 可以看到 Micro Service 间拓扑关系:


2 部署 DestinationRule

kubectl apply -f samples/bookinfo/networking/destination-rule-all.yaml
复制代码


配置文件内容:


apiVersion: networking.istio.io/v1alpha3kind: DestinationRulemetadata: name: productpagespec: host: productpage subsets: - name: v1   labels:     version: v1---apiVersion: networking.istio.io/v1alpha3kind: DestinationRulemetadata: name: reviewsspec: host: reviews subsets: - name: v1   labels:     version: v1 - name: v2   labels:     version: v2 - name: v3   labels:     version: v3---apiVersion: networking.istio.io/v1alpha3kind: DestinationRulemetadata: name: ratingsspec: host: ratings subsets: - name: v1   labels:     version: v1 - name: v2   labels:     version: v2 - name: v2-mysql   labels:     version: v2-mysql - name: v2-mysql-vm   labels:     version: v2-mysql-vm---apiVersion: networking.istio.io/v1alpha3kind: DestinationRulemetadata: name: detailsspec: host: details subsets: - name: v1   labels:     version: v1 - name: v2   labels:     version: v2---
复制代码


这个 Destination Rule 中包含每个子应用的不同版本。此时在刷新网页时,可以看到 3 个版本的 Review。


通过脚本持续的访问页面:


for i in {1..100}; do curl -o /dev/null -s -w %{http_code} \         http://35.188.64.161/productpage; sleep 1; done
复制代码


此时流量是基本均担的:


3 配置 VirtualService 流量导向 v1

kubectl apply -f samples/bookinfo/networking/virtual-service-all-v1.yaml
复制代码


配置文件内容:


apiVersion: networking.istio.io/v1alpha3kind: VirtualServicemetadata: name: productpagespec: hosts: - productpage http: - route:   - destination:       host: productpage       subset: v1---apiVersion: networking.istio.io/v1alpha3kind: VirtualServicemetadata: name: reviewsspec: hosts: - reviews http: - route:   - destination:       host: reviews       subset: v1---apiVersion: networking.istio.io/v1alpha3kind: VirtualServicemetadata: name: ratingsspec: hosts: - ratings http: - route:   - destination:       host: ratings       subset: v1---apiVersion: networking.istio.io/v1alpha3kind: VirtualServicemetadata: name: detailsspec: hosts: - details http: - route:   - destination:       host: details       subset: v1---
复制代码


可以看到,所有的流量都导向 v1 的 subset。包括 productpage、reviews、ratings、details。此时再刷新页面,都只有相同的内容。


4 配置 VirtualService 通过识别 http header 内容进行控制流量

VirtualService 可以通过 http header 中的内容对流量进行控制。这里采用用户名来进行控制:


kubectl apply  \   -f samples/bookinfo/networking/virtual-service-reviews-test-v2.yaml
复制代码


配置文件内容:


apiVersion: networking.istio.io/v1alpha3kind: VirtualServicemetadata: name: reviewsspec: hosts:   - reviews http: - match:   - headers:       end-user:         exact: jason   route:   - destination:       host: reviews       subset: v2 - route:   - destination:       host: reviews       subset: v1
复制代码


可以看到,如果用户是 jason,流量将导向 v2,否则导向 v1.


使用 jason 登录,可以看到 review 的页面是下面黑色的星星。是 v2 的 subset。



退出登录,或用随意的名字登录,都是没有星星的 v1 版本:


5 配置 VirtualService 流量导向 v1 和 v3 各一半

清除上面实验的配置:


kubectl delete \      -f samples/bookinfo/networking/virtual-service-all-v1.yaml
复制代码


此时流量会在 3 个版本间轮训。


下面的配置会只导向 v1:


kubectl apply \      -f samples/bookinfo/networking/virtual-service-all-v1.yaml
复制代码


采用下面的配置,把流量在 v1 和 v3 间各 50%分流:


kubectl apply \    -f samples/bookinfo/networking/virtual-service-reviews-50-v3.yaml
复制代码


配置的具体内容:


apiVersion: networking.istio.io/v1alpha3kind: VirtualServicemetadata: name: reviewsspec: hosts:   - reviews http: - route:   - destination:       host: reviews       subset: v1     weight: 50   - destination:       host: reviews       subset: v3     weight: 50
复制代码


此时可以看到流量在 v1 和 v3 间轮询:




6 配置 VirtualService 流量导向 v3

应用如下配置:


kubectl apply \      -f samples/bookinfo/networking/virtual-service-reviews-v3.yaml
复制代码


配置的具体内容如下:


apiVersion: networking.istio.io/v1alpha3kind: VirtualServicemetadata: name: reviewsspec: hosts:   - reviews http: - route:   - destination:       host: reviews       subset: v3
复制代码


这样流量都导向 v3:



7 配置 VirtualService 流量导向 v1 和 v2,比例 9:1

应用如下配置:


kubectl apply \    -f samples/bookinfo/networking/virtual-service-reviews-90-10.yaml
复制代码


配置的具体内容如下:


apiVersion: networking.istio.io/v1alpha3kind: VirtualServicemetadata: name: reviewsspec: hosts:   - reviews http: - route:   - destination:       host: reviews       subset: v1     weight: 90   - destination:       host: reviews       subset: v2     weight: 10
复制代码


此时 90%流量导向 v1,10%的流量导向 v2。可以通过多刷页面看到 v2 的黑色星星页面。


四 总结

通过在 GKE 上的 Istio 的 Gateway/VirtualService/DestinationRule 可以非常方便的控制各个微服务间的流量调度。
